1. Whole bed: carbon steel electrostatic spray molding; The bed surface and guardrail aremade of ABS engineering plastics and imported ABS raw materials, which are non-toxicand tasteless,with impact resistance, heat resistance, low temperature resistance andchemical resistance;
2.Guardrail: ABS segmented guardrails on both sides, with buffer damping device, whichcan be quietly lowered and hidden to the bed surface;
3.Back lifting: the back can be tilted, and the air pressure control design, within the rangeof 60 degrees, can be positioned at will and is very safe, and can be operated with onehand;
4.Casters: equipped with universal and directional casters, central control braking system,one foot braking and four-wheel braking.The four wheels are made of polyurethanecentral control wheels with a diameter of 150mm, double-sided wheel design, embeddedwith double bearings, and the rotation is flexible and stable.Pass the international Pennytest. The castor core material is made of high-strength aluminum alloy with high strength;The castor is wrapped with polyether PU material, which is silent, shock-absorbing, wear-resistant and corrosion-resistant solution;
5.Crank: limit clutch manual lifting handle, with automatic limit protection device, hiddenmanual crank;
6.Two or four guardrails are available, and the mattress can be customized.
7.Back lift:O-60°士5°
8.Overall lifting:645-910mm
9.Max capacity:200KG
10.0verall dimension after docking:3850*800mm
11.Bed size:1960*640
12.Total length of inner diameter after butt joint:3610mm
13.Bed width:640mm
1. Whole bed: carbon steel electrostatic spray molding; The bed surface and guardrail aremade of ABS engineering plastics and imported ABS raw materials, which are non-toxicand tasteless,with impact resistance, heat resistance, low temperature resistance andchemical resistance;
2.Guardrail: ABS segmented guardrails on both sides, with buffer damping device, whichcan be quietly lowered and hidden to the bed surface;
3.Back lifting: the back can be tilted, and the air pressure control design, within the rangeof 60 degrees, can be positioned at will and is very safe, and can be operated with onehand;
4.Casters: equipped with universal and directional casters, central control braking system,one foot braking and four-wheel braking.The four wheels are made of polyurethanecentral control wheels with a diameter of 150mm, double-sided wheel design, embeddedwith double bearings, and the rotation is flexible and stable.Pass the international Pennytest. The castor core material is made of high-strength aluminum alloy with high strength;The castor is wrapped with polyether PU material, which is silent, shock-absorbing, wear-resistant and corrosion-resistant solution;
5.Crank: limit clutch manual lifting handle, with automatic limit protection device, hiddenmanual crank;
6.Two or four guardrails are available, and the mattress can be customized.
7.Back lift:O-60°士5°
8.Overall lifting:645-910mm
9.Max capacity:200KG
10.0verall dimension after docking:3850*800mm
11.Bed size:1960*640
12.Total length of inner diameter after butt joint:3610mm
13.Bed width:640mm
